1J22 Precision Soft Magnetic Alloy Round Rod Hiperco 50 Alloy High Magnetic Permeability
| MOQ: | 100KG |
| Price: | Price is negotiated based on the required specifications and quantity |
| Standard Packaging: | Standard export packaging, or packaging as required |
| Delivery Period: | 5-8 working days, depending on the parameters required for negotiation |
| Payment Method: | Payment Terms: Mainly T/T.. L/C, D/A, D/P, |
| Supply Capacity: | 5000 tons per month |
Detail Information
Place of Origin
China
Brand Name
Zhonggong Special Metallurgy
Certification
ISO Certificate
Model Number
1j22 soft magnetic precision alloy
Density:
8.20g/cm3
Product Surface:
Black Or Bright
Specification And Size:
Cut According To Customer Requirements
Chemical Composition:
High Saturation Magnetic Induction Intensity Iron Cobalt Vanadium Soft Magnetic Alloy
Product:
Bars, Plates, Pipes, Forgings, Etc
Saturation Magnetic Induction:
High
Excellent:
Resilience
Workability:
Yes
Highlight:
Precision Hiperco 50 Alloy
,Soft Magnetic Alloy Rod
,1J22 Soft Magnetic Alloy
Product Description
1J22 Precision Soft Magnetic Alloy Round Rod Hiperco 50 Alloy High Magnetic Permeability
Product Attributes
| Attribute | Value |
|---|---|
| Density | 8.20g/cm3 |
| Product Surface | Black Or Bright |
| Specification And Size | Cut According To Customer Requirements |
| Chemical Composition | High saturation magnetic induction intensity iron cobalt vanadium soft magnetic alloy |
| Product | Bars, plates, pipes, forgings, etc |
| Saturation Magnetic Induction | High |
| Excellent | Resilience |
| Workability | Yes |
Product Description
High magnetic permeability 1J22 soft magnetic precision alloy rod Hiperco 50 optical round rod
Introduction to 1J22 Material
1J22 is a high saturation magnetic induction iron cobalt vanadium soft magnetic alloy with the following characteristics:
- High saturation magnetic induction intensity: Among existing soft magnetic materials, 1J22 has the highest saturation magnetic induction intensity, reaching 2.4T.
- High Curie point: With a Curie point of 980℃, it can operate at higher temperatures where other soft magnetic materials have completely demagnetized, maintaining good magnetic stability.
- Large magnetostriction coefficient: The maximum saturation magnetostriction coefficient is 60-100 × 10-6, which is extremely suitable for making magnetostrictive transducers with high output energy and high work efficiency.
Chemical Composition of 1J22
The precise ratio of these components ensures the high saturation magnetic induction intensity and good mechanical properties of 1J22.
| Fe | Co | V | C | Mn | Si | P | S | Cu | Ni |
| Excess | 49.0-51.0% | 0.80-1.80% | ≤ 0.04% | ≤ 0.30% | ≤ 0.30% | ≤ 0.020% | ≤ 0.020% | ≤ 0.20% | ≤ 0.50% |
Density: 8.20g/cm³
Physical Properties
- Magnetic properties: Saturation magnetic induction intensity is 2.4T, and Curie point is 980℃
- Electrical performance: Resistivity is 0.27 μΩ*m, not suitable for use at high frequencies
- Thermal performance: Thermal conductivity is 7.7 W/(m*K), and coefficient of thermal expansion is 5.1 × 10^-6/K
Characteristics of 1J22 Alloy
- Ultra high strength: Tensile strength can reach over 2000 MPa, several times that of ordinary steel
- Good processing performance: Easy to cut, forge, and weld, suitable for manufacturing complex precision components
- Wear resistance: Extremely high hardness and excellent wear resistance
- Corrosion resistance: Chromium element gives resistance to acid and alkali corrosion, maintaining performance in harsh environments
