Polished TC11 BT9 Titanium Alloy Rods Diameter 5mm - 200mm Titanium Alloy Round Bar
| MOQ: | 100KG |
| Price: | Price is negotiated based on the required specifications and quantity |
| Standard Packaging: | Standard export packaging, or packaging as required |
| Delivery Period: | 5-8 working days, depending on the parameters required for negotiation |
| Payment Method: | Payment Terms: Mainly T/T.. L/C, D/A, D/P, |
| Supply Capacity: | 5000 tons per month |
Detail Information
Place of Origin
China
Brand Name
Zhonggong Special Metallurgy
Certification
ISO Certificate
Model Number
TC11 Titanium Alloy
Level:
Gr1, Gr2, Gr3, Gr5, Gr7, Gr9, Gr11, Gr12, Gr16, Gr17, Gr23
Model:
TC11 BT9 Titanium Alloy Bar
Name:
Ti-6.5Al-3.5Mo-1.5Zr-0.3Si
Density:
4.48g/cm³
Alloy:
α+β Duplex Titanium Alloy
Applications:
Industrial And Medical
Length:
As Required
Quality Assurance:
Titanium Sponge Material, Standardized Production
Highlight:
BT9 Polished Titanium Alloy Rods
,Titanium Alloy Rods 5mm
,200mm Titanium Alloy Round Bar
Product Description
Polished TC11 BT9 Titanium Alloy Rods Diameter 5mm - 200mm Titanium Alloy Round Bar
Product Specifications
| Attribute | Value |
|---|---|
| Level | Gr1, Gr2, Gr3, Gr5, Gr7, Gr9, Gr11, Gr12, Gr16, Gr17, Gr23 |
| Model | TC11 BT9 Titanium Alloy Bar |
| Name | Ti-6.5Al-3.5Mo-1.5Zr-0.3Si |
| Density | 4.48g/cm³ |
| Alloy | α+β Duplex Titanium Alloy |
| Applications | Industrial and medical |
| Length | As required |
| Quality assurance | Titanium sponge material, standardized production |
Product Overview
TC11 is an α+β dual-phase titanium alloy with excellent thermal strength, high room temperature strength and superior hot processing performance. Designed for long-term use at 500℃, it's ideal for manufacturing critical aircraft engine components like disks and blades.
With its low density and high specific strength across temperature ranges (-253℃ to 600℃), TC11 titanium alloy effectively replaces traditional materials like steel and aluminum in aviation applications, including rocket engine rotating parts.
Technical Specifications
| Material | Diameter | Length | Surface | Supply State |
|---|---|---|---|---|
| TC11(BT9) | 1.0mm - 300mm | 100mm-6000mm | Bright | Annealed |
Chemical Composition
| Chemical Components | Impurities ≤ |
|---|---|
| Al: 5.8-7.0 Mo: 2.8-3.8 Zr: 0.8-2.0 Si: 0.20-0.35 Ti: Balance |
Fe: 0.25 C: 0.10 N: 0.05 H: 0.012 O: 0.15 Other: 0.10 Total: 0.40 |
Key Advantages
- Excellent high temperature strength and creep resistance below 500℃
- Superior thermal working performance with versatile welding and machining capabilities
- Enhanced oxidation resistance compared to Ti-6Al-4V alloy
- Rigorous testing including tensile strength, hardness, and chemical composition analysis
- High precision surface quality with no cracks or peeling
- Non-magnetic and non-toxic properties
- Exceptional corrosion resistance in seawater, chlorides, acids, and other harsh environments
Specializing in premium titanium alloys with commitment to quality and long-term partnerships.
